Double wall Drawer System Dragon box mm00-350
- Full-extension slides for complete drawer access
-
Integrated soft-close mechanism ensures silent and smooth operation
-
High load capacity: supports up to 40 kg (88 lbs)
-
Standard drawer side height: 83 mm
-
Available lengths: 400 mm, 450 mm, and 500 mm
-
Color options: Grey and White
-
Tool-less assembly and removal for efficient installation
-
Production pack includes: 20 pairs of drawer sides and 20 pairs of soft-closing slides
-
Front fixing brackets, rear fixing brackets, and cover caps sold separately
Product Description – Double wall Drawer System Dragon box mm00-350(Production Packs)
This doublewall drawer system is designed to deliver optimal durability, functionality, and a sleek modern finish — making it a top-tier choice for kitchen manufacturers, cabinetmakers, and furniture designers. Engineered with premium materials and a dual-wall metal structure, it combines a clean aesthetic with superior load capacity and soft-close performance.
The full-extension mechanism provides complete access to drawer contents, while the built-in soft-closing slides ensure a smooth, silent operation with every use. This system is ideal for high-traffic areas and long-term use, offering both strength and convenience in a production-friendly package.
Whether you’re outfitting a kitchen, bathroom, or office space, this drawer system integrates easily into a variety of cabinet designs with its quick-installation feature and reliable performance.
📋 Technical Specifications Table(Double wall Drawer System Dragon box mm00-350)
| Specification | Details |
|---|---|
| Type | Doublewall Metal Drawer System |
| Drawer Side Height | 83 mm |
| Drawer Lengths Available | 400 mm, 450 mm, 500 mm |
| Extension Type | Full-extension runners |
| Closing Mechanism | Integrated soft-close |
| Load Capacity | Up to 40 kg (88 lbs) |
| Color Options | White, Grey |
| Material | Powder-coated steel |
| Installation | Tool-free assembly and removal |
| Included in Production Pack | 20 pairs of drawer sides + 20 pairs of slides |
| Accessories (sold separately) | Front/rear fixing brackets, cover caps |
| Recommended Applications | Kitchens, wardrobes, bathroom furniture, offices |
✅ Benefits:
-
Clean modern design with high-quality finish
-
High load-bearing capacity for everyday use
-
Effortless installation – ideal for production lines
-
Soft-close motion prevents slamming and extends drawer life
-
Multiple sizes for flexible cabinet design
